SIP/Android Video Conferencing Solution

The GVC3200 is a ground-breaking solution that offers businesses a revolutionary video conferencing system with unprecedented flexibility and the power of support for multiple popular video conferencing protocols and platforms right out of the box. The SIP-based GVC3200 supports Grandstream’s robust IPVideoTalk platform for plug and play video conferencing while also being interoperable with any 3rd party SIP video conferencing platform - thus offering a great option to expand or implement a 3rd party platform. The GVC3200 sports an innovative, patent-pending embedded MCU that supports up to 9-way conferencing with local mixing between SIP and other protocols.

Features

  • Bluetooth

    Bluetooth

    Built-in Bluetooth for use with Bluetooth speakers/ microphones, keyboards, data exchange, etc. keyless entry

  • HDMI

    HDMI

    Support for 3 screens thanks to 3 HDMI outputs

  • Gigabit Network

    Gigabit Network

    Experience the fastest possible connections speeds to maximize video quality

  • 1080P Video Resolution

    1080P Video Resolution

    Experience video resolutions up to 1080p

  • Zoom Clarity

    Zoom Clarity

    A powerful 12x optical zoom offers robust video clarity

  • Wi-Fi

    Wi-Fi

    Dual-band Wi-Fi support offers mobility

  • Embedded MCU

    Embedded MCU

    Embedded MCU to allow up to 9 video attendees

  • Screen share

    Screen share

    Share a presentation with conference attendees or review a document.

  • Controllable PTZ

    Controllable PTZ

    Local & far-end controllable PTZ camera with wideangle lens

  • Record

    Record

    Easily record all video conferences to document meetings

Technical Specification

Protocols/Standards
SIP RFC3261, BFCP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV,
NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP,
TCP/IP/UDP, IPv6, FEC, FECC
Camera
1/3” 2 Megapixel CMOS 1920Hx1080V@30fps
Lens
12x optical zoom, +/-23° tilt, +/- 90° pan, 70°(W)*- 6.3° (T) field of view
Network Interface
1× RJ45 10/ 100/ 1000 Mbps port
Wi-Fi
Yes, integrated dual-band 802.11 a/b/g/n (2.4GHz & 5GHz)
Bluetooth
Yes, integrated. Bluetooth 4.0 + EDR
Video Outputs
3x HDMI up to 1080p with CEC
Video Input
1x VGA/1x HDMI with resolution up to 1080p
Microphone/Speaker
External MIC/Speaker, built-in MIC, cascadable external MIC/speaker (pending)
Remote Control
Bluetooth remote control with multi-touch touchpad
Auxiliary Ports
1x USB 2.0, SD, external speaker port, reset pin
Graphic Display
OLED with 128x32 resolution
Voice Codecs
G.711μ/a, G.722 (wide-band), iLBC (pending), Opus, G.722.1, G.722.1c (pending), in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO)
Video Codecs
H.264 BP/MP/HP, video resolution up to 1080p, frame rate up to 30 fps, bitrate up to 4Mbps
People Video Resolution
1080p from 512 Kbps, 720p from 384 Kbps, 4SIF/4CIF from 128 Kbps, SIF/CIF/QSIF/QCIF/SQSIF/SQCIF from 64 Kbps
Content Video Resolution
Input: VGA, SVGA, XGA, WXGA, WXGA, SXGA, 1440×900, 720p, 1600×1200, 1080p (HDMI), up to 60fps; Encoding: 1280×720, 1920×1080
Output Resolution
720p, 1080p
Embedded MCU
Up to 4-way 1080p conference, 5-way 720p conference, 9-way VGA conference
Dual-Stream
BFCP, people video (up to 1080p@30fps) + content video (up to 1080p@15fps, 720p@30fps)
Audio Features
AEC, ANS, AGC, PLC, CNG/VAD
Video Features
FEC, dynamic display layout, picture-in-picture, picture-outside-picture, digital caption (pending)
Platform Bridging
Bridge SIP calls with Android VoIP apps
Telephony Features
Hold, transfer, forward (unconditional/no-answer/busy), call park/pickup, 9-way audio/video conference,
downloadable XML phone book, LDAP, call waiting, call history, flexible dial plan, personalized music ringtones, server redundancy & fail-over
Sample Applications
Web browser, Facebook, Twitter, YouTube, Google calendar, mobile phone data import/export via Bluetooth,
etc. API/SDK available for advanced custom application development
Application Deployment
Allows Android 4.4.2 compliant applications to be deployed in the device with provisioning control
QoS
Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted
configuration file, TLS, 128/256-bit SRTP, HTTPS, 802.1x media access control
Multi-Language
English, German, Italian, French, Spanish, Portuguese, Russian, Turkish, Polish, Chinese, Korean, Japanese and more
Upgrade/Provisioning
Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload, mass provisioning using TR-069 or AES
encrypted XML configuration file
Power
Universal power adapter included: Input 100-240VAC 50-60Hz; Output 12VDC/5A (60W)
