IP Phone-Grandstream GXP1630

The GXP1630 is a powerful IP phone for small-to-medium businesses (SMBs). This Linux-based model includes 3 lines, 3 XML programmable soft keys, 8 BLF keys and 4-way conferencing. A 132x64 (2.98’’) backlit LCD screen creates a clear display for easy viewing. Additional features such as dual switched gigabit network ports, HD audio, multi-language support, integrated PoE and call-waiting allow the GXP1630 to be a high quality, versatile and dependable office phone.

Features

  • 3 lines

    3 lines

    3 lines, 3 SIP accounts, 3 call apperances, 3 softkeys

  • Gigabit

    Gigabit

    Dual-switched auto-sensing 10/100/1000mbps network ports

  • Speed Dials

    Speed Dials

    Includes 8 dual-colored BLF/speed dial keys

  • POE

    POE

    Built-in PoE+ to power the device and give it a network connection

  • HD Audio

    HD Audio

    HD audio to maximize audio quality and clarity, full-depulex speakerphone

  • Zero Config

    Zero Config

    Use with Grandstream’s UCM series of IP PBXs for Zero Config provisioning

  • EHS Headsets

    EHS Headsets

    Electronic Hook Switch (EHS) support for Plantronics headsets

  • Automated Provisioning

    Automated Provisioning

    Automated provisioning options include TR-069 and XML config files

  • Secure

    Secure

    TLS and SRTP security encryption technology to protect calls and accounts

  • Audio Conferencing

    Audio Conferencing

    4-way audio conferencing for easy conference calls

Technical Specification

Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record,
SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP,
TR-069, 802.1x, TLS, SRTP, CDP/SNMP/RTCP-XR
Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Ethernet ports, integrated PoE
Graphic Display
132 x 64 (2.98’’) backlit graphical LCD display
Feature Keys
3 line keys with dual-color LED and 3 SIP accounts, 3 XML programmable context
sensitive soft keys, 5 (navigation, menu) keys, 8 BLF keys
Voice Codecs
Support for G.711µ/a, G.722 (wide-band), G.723, G.726-32, G.729 A/B, iLBC, in-band
and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC
Telephony Features
Hold, transfer, forward (unconditional/no-answer/busy), call park/pickup, 4-way conference, shared-call-appearance (SCA) / bridged-line-appearance (BLA), downloadable phone book (XML, LDAP, up to 1000 items)
Headset Jack
RJ9 headset jack (allowing EHS with Plantronics headsets)
HD Audio
Yes, HD handset and speakerphone with support for wideband audio
Base Stand
Yes, 2 angled positions available, wall mountable
Wall Mountable
Yes
QoS
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 QoS (ToS, DiffServ, MPLS)
Security
User and administrator level access control, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media
access control
Power
Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA; PoE:
IEEE802.3af Class 2, 3.84W-6.49W; IEEE802.3az (EEE)
