GXP1760

GXP1760

IP Phone-Grandstream GXP1760

The GXP1760 is a mid-range IP phone with a sleek design and moderate call-volume features. It comes equipped with 6 lines, 3 SIP accounts, 6 dual-color line keys and 4 XML programmable context sensitive soft keys on a 200 x 80 pixel (3.3”) back-lit LCD display screen. For added personalization the GXP1760 features personalized ring tone/ring back tone music and integration with advanced web and enterprise applications as well as local weather services. It’s also one of the first Grandstream phones to come equipped with a Kensington Security Slot— one of the most popular anti-theft solutions on the market. The GXP1760 offers dual auto-sensing 10/100Mbps network ports and supports automated provisioning features with media access control. This mid-range IP phone delivers outstanding performance and design to users worldwide at a budget-friendly price point.

Features

  • 6 Lines

    6 Lines

    6 lines, 6 dual-color line keys (with 3 SIP accounts), 4 XML programmable contextsensitive soft keys

  • Audio Conferencing

    Audio Conferencing

    5-way audio conferencing for easy conference calls

  • Speed Dials

    Speed Dials

    24 digitally programmable & customizable BLF/fastdial keys

  • USB

    USB

    Built-in USB port for importing and exporting data only

  • HD Audio

    HD Audio

    HD wideband audio, full-duplex hands-free speakerphone with advanced acoustic echo cancellation

  • POE

    POE

    Built-in PoE to power the devices and give it a network connection

  • EHS Headsets

    EHS Headsets

    Supports EHS compatible Plantronics’s headsets

  • Automated Provisioning

    Automated Provisioning

    Automated provisioning using TR069 or AES encrypted XML configuration file

  • Phonebook

    Phonebook

    Large phonebook capacity with up to 2000 contacts and call history with up to 500 records

  • Security

    Security

    TLS and SRTP security encryption technology to protect calls & accounts and Kensington Security Slot support

  • Zero Config

    Zero Config

    Use with Grandstream’s UCM series IP PBX appliance for ZeroConfig provisioning, 1-touch call recording & more

Technical Specification

Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS(A record,
SRV, NAPTR), DHCP, PPPoE, TELNET, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR-069, 802.1x, TLS, SRTP, IPV6
Network Interfaces
Dual switched auto-sensing 10/100Mbps ethernet ports with integrated POE
Graphic Display
200 x 80 pixel (3.3’’) backlit LCD display
Bluetooth
No
Feature Keys
6 line keys with up to 3 SIP accounts, 4 XML programmable context sensitive
softkeys, 5 navigation/menu keys, 8 dedicated function keys for:
PHONEBOOK, TRANSFER, CONFERENCE, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOLUME
Voice Codecs
Support for G.729A/B, G.711μ/a-law, G.726, G.722 (wide-band), G.723, iLBC,
OPUS, in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), USB, and a sepa- rate EHS port reserved for external EHS adapter in the future
Telephony Features
Hold, transfer, forward, 5-way conference, call park, call pickup, shared-callappearance(SCA)/bridged-line-appearance(BLA), downloadable phonebook (XML,
LDAP, up to 2000 items), call waiting, call log (up to 500 records)
HD audio
Yes, HD handset and speakerphone with support for wideband audio
Base Stand
Yes, 2 angle positions available. Wall Mount stand sold separately
QoS
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x
media access control, Kensington Security Slot (Kensington Lock) support
Multi-language
English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, Chinese, Korean, Japanese
Upgrade/Provisioning
Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR-069 or AES encrypted XML configuration file
Power
Universal power adapter included:Input:100-240V; Output: +5V, 1A;
Integrated Power-over-Ethernet (802.3af)
Max power consumption : 5W
Physical
Dimension: 231mm(W) x 167mm(L) x 86mm(H); Unit weight:0.925kg ; Package
weight:1.55kg
Temperature and Humidity
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing
Package Content
GXP1760 phone, handset with cord, base stand, universal power supply,
network cable, Quick Installation Guide, GPL license
