IP Phone-Grandstream GXP1780/1782

The GXP1780/1782 is a powerful mid-range IP phone with advanced telephony features. This mid-range IP phone comes equipped with 8 lines, 4 SIP accounts, 8 dual-color line keys and 4 XML programmable context sensitive soft keys on a 200 x 80 pixel (3.3”) back-lit LCD display screen. For added personalization the GXP1780/1782 features personalized ring tone/ring back tone music and integration with advanced web and enterprise applications. It’s also one of the first Grandstream phones to come equipped with a Kensington Security Slot— one of the most popular anti-theft solutions on the market. The GXP1780/1782 supports the fastest possible connection speeds with dual auto-sensing Gigabit network ports (on GXP1782 only) as well as automated provisioning features with media access control. The GXP1780/1782 is the perfect fit for users looking for a featured-pack IP phone that delivers high-performance and design at an affordable price point.

Features

  • Audio Conferencing

    Audio Conferencing

    5-way audio conferencing for easy conference calls

  • Speed Dial

    Speed Dial

    32 digitally programmable & customizable BLF/fastdial keys

  • USB

    USB

    Built-in USB port for importing and exporting data only

  • HD Audio

    HD Audio

    HD wideband audio, full-duplex hands-free speakerphone with advanced acoustic echo cancellation

  • POE

    POE

    Built-in PoE to power the devices and give it a network connection

  • EHS Headsets

    EHS Headsets

    Supports EHS compatible Plantronics’s headsets

  • Automated provisioning

    Automated provisioning

    Automated provisioning using TR-069 or AES encrypted XML configuration file

  • Phonebook

    Phonebook

    Large phonebook capacity with up to 2000 contacts and call history with up to 500 records

  • Security

    Security

    TLS and SRTP security encryption technology to protect calls & accounts & Kensington Security Slot support

  • Zero Config

    Zero Config

    Use with Grandstream’s UCM series IP PBX appliance for Zero-Config provisioning, 1-touch call recording & more

  • Gigabit

    Gigabit

    Dual switched auto-sensing 10/100Mbps (GXP1780) and 10/100/1000Mbps (GXP1782) Gigabit network ports

  • 8 Lines

    8 Lines

    8 lines, 8 dual-color line keys (with 4 SIP accounts), 4 XML programmable context-sensitive soft keys

Technical Specification

Protocols/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS(A record,
SRV, NAPTR), DHCP, PPPoE, SSH, TELNET, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR-069, 802.1x, TLS, SRTP, IPV6
Network Interfaces
Dual switched Ethernet ports with integrated PoE. Auto-sensing 10/100Mbps
(GXP1780), 10/100/1000Mbps (GXP1782)
Graphic Display
200 x 80 pixel (3.3’’) backlit LCD display
Bluetooth
No
Feature Keys
8 line keys with up to 4 SIP accounts, 4 XML programmable context sensitive
softkeys, 5 navigation/menu keys, 8 dedicated function keys for:
PHONEBOOK, TRANSFER, CONFERENCE, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE, VOLUME
Voice Codecs
Support for G.729A/B, G.711μ/a-law, G.726, G.722 (wide-band), G.723, iLBC,
OPUS, in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), USB, and a separate EHS port reserved for external EHS adapter in the future.
Telephony Features
Hold, transfer, forward, 5-way conference, call park, call pickup, sharedcall-appearance(SCA)/bridged-line-appearance(BLA), downloadable
phonebook(XML, LDAP, up to 2000 items), call waiting, call log(up to 500 records)
HD audio
Yes, HD handset and speakerphone with support for wideband audio
Base Stand
Yes, 2 angle positions available. Wall Mount stand sold separately.
QoS
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based
authentication, 256-bit AES encrypted configuration file, SRTP, TLS, 802.1x
media access control, Kensington Security Slot (Kensington Lock) support
Multi-language
English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, Chinese, Korean, Japanese
Upgrade/Provisioning
Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR-069 or AES encrypted XML configuration file.
Power
Universal power adapter included: Input:100-240V; Output: +5V, 1A;
Integrated Power-over-Ethernet (802.3af)
Max power consumption: 5W
Physical
Dimension: 231mm(W) x 167mm(L) x 86mm(H); Unit weight:0.925kg ; Package weight:1.55kg
Temperature and Humidity
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing
Package Content
GXP1782/GXP1780 phone, handset with cord, base stand, universal power
supply, network cable, Quick Installation Guide, GPL license
