IP Phone-Grandstream GXP2160

The GXP2160 is a Linux-based device with 6 lines, 5 XML programmable soft keys, and 5-way conferencing. HD audio and a 4.3 inch (480 x 272) color LCD screen create high quality calls, while the 24 BLF keys, Bluetooth, USB and EHS add versatility. The GXP2160 is perfect for Enterprise & SMB customers with the need for quality and versatility in their desktop communications.


  • 6 Lines

    6 Lines

    6 lines, with up to 6 SIP accounts, 6 dualcolored line keys

  • Gigabit


    Dual-switched auto-sensing 10/100/1000mbps network ports

  • Programmable BLF

    Programmable BLF

    24 dual-colored and programmable BLF/ speed dial keys

  • Bluetooth


    Built-in Bluetooth for syncing headsets and mobile devices for contact books, calendars & call transferring

  • HD Audio

    HD Audio

    HD audio to maximize audio quality and clarity, full-duplex speakerphone

  • POE


    Built-in PoE to power the device and give it a network connection

  • EHS Headsets

    EHS Headsets

    Supports EHS compatible Plantronics’s headsets

  • Automated Provisioning

    Automated Provisioning

    Automated provisioning using TR-069 or AES encrypted XML configuration file

  • USB


    Built-in USB ports for importing/exporting data

  • Audio Conferencing

    Audio Conferencing

    5-way audio conferencing for easy conference calls

  • Secure


    TLS and SRTP security encryption technology to protect calls and accounts

Technical Specification

Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with
integrated PoE
Yes, Bluetooth V2.1
Feature Keys
6 line keys with up to 6 SIP accounts, 24 speed-dial/BLF extension keys with
dual-color LED, 5 programmable context sensitive softkeys, 5 navigation/menu
keys, 11 dedicated function keys for
Voice Codecs
Support for G.729A/B, G.711µ/a-law, G.726, G.722(wide-band), G723.1, iLBC,
Opus, in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO)
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), USB
Sample Applications
Weather, currency, news, XML
HD Audio
Yes, both on handset and speakerphone
Base Stand/Wall Mountable
Yes, allow 2 angle positions
Layer 2 (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Universal power adapter included: Input: 100-240VAC; Output: ,+12V, 1.0A
Integrated PoE (Power-over-Ethernet) 802.3af,
Max power consumption: 6W
