IP Phone-Grandstream GXP2170

The GXP2170 is a powerful enterprise-grade IP phone that is ideal for busy users who handle high call volumes. This top-of-the-line Enterprise IP Phone features up to 12 line keys/line appearances and 6 SIP accounts using a 4.3 inch (480 x 272) color display LCD and full HD audio. It includes up to 48 digital, on-screen speed dial/BLF keys to help users be more productive and efficent. The GXP2170 supports the fastest possible connection speeds with dual Gigabit network ports, features integrated PoE and includes built-in Bluetooth for syncing with mobile devices and Bluetooth headsets. This Enterprise IP phone can connect to up to four GXP2200 EXT modules with LCD display to access up to 160 speed dial/BLF contacts. The GXP2170 is the perfect choice for enterprise users looking for a top-notch executive IP phone with advanced functionality.


  • Gigabit


    Dual-switched auto-sensing 10/100/1000mbps network ports

  • Programmable BLF

    Programmable BLF

    48 digitally programmable & customizable BLF/fastdial keys, and supports up to 4 cascaded GXP2200EXT Modules

  • Bluetooth


    Built-in Bluetooth for syncing headsets and mobile devices for contact books, calendars & call transferring

  • HD Audio

    HD Audio

    HD audio to maximize audio quality and clarity, full-duplex speakerphone

  • POE


    Built-in PoE to power the device and give it a network connection

  • EHS Headsets

    EHS Headsets

    Supports EHS compatible Plantronics’s headsets

  • Automated provisioning

    Automated provisioning

    Automated provisioning using TR-069 or AES encrypted XML configuration file

  • USB


    Built-in USB ports for importing/exporting data

  • Audio Conferencing

    Audio Conferencing

    5-way audio conferencing for easy conference calls

  • Secure


    TLS and SRTP security encryption technology to protect calls and accounts

  • Zero Config

    Zero Config

    Use with Grandstream’s UCM series IP PBX appliance for Zero-Config provisioning, 1-touch call recording & more

  • 12 Lines

    12 Lines

    12 dual-color line keys (with 6 SIP accounts), 5 XML programmable context-sensitive soft keys

Technical Specification

Yes, Integrated
Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with integrated
Extension Module
Yes, can power up to 4 GXP2200EXT modules which features a 128x384 graphic LCD,
20 quick-dial/BLF keys which dual-color LED, 2 navigation keys, and less than 1.2W
power consumption per unit.
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 (ToS, DiffServ, MPLS) QoS
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), USB, extension module port
Base Stand
Yes, 2 angle positions available, Wall Mountable
Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR-069 or AES
encrypted XML configuration file, FTP/FTPS
Universal power adapter included: Input:100-240V ; Output: +12V, 1.0A
